Amazon ECR

Auth

ocync auto-detects ECR private from the hostname (*.dkr.ecr.*.amazonaws.com) and uses ambient AWS credentials via the AWS SDK. The credential chain follows AWS conventions:

  • Environment variables (AWS_ACCESS_KEY_ID, AWS_SECRET_ACCESS_KEY, AWS_SESSION_TOKEN)
  • Shared credentials file (~/.aws/credentials)
  • Container or instance role (ECS task role, EC2 instance profile, Lambda execution role)
  • IRSA or EKS Pod Identity (cluster-side identity binding)

No Docker config or static credentials are needed. See the AWS credential precedence docs for the full chain.

Notable behaviors:

  • HTTP Basic, not Bearer exchange. SDK GetAuthorizationToken returns a base64-encoded AWS:<password> blob that the registry accepts directly; ocync sends Authorization: Basic <token> and skips the /v2/token round-trip.
  • FIPS endpoints: set AWS_USE_FIPS_ENDPOINT=true to route SDK calls through *.dkr.ecr-fips.<region>.amazonaws.com. See the FIPS guide for crypto provider details.
  • Cross-repo blob mounting requires BLOB_MOUNTING=ENABLED on the account and a committed manifest in the source repo that references the specific blob. Enable per-account: aws ecr put-account-setting --name BLOB_MOUNTING --value ENABLED. Mount POSTs returning 202 (not yet fulfilled) fall back to a normal upload.
  • Batch existence checks use BatchCheckLayerAvailability (up to 100 digests per call) instead of per-blob HEADs, reducing API volume on cold syncs.
  • Per-action rate limits: ECR enforces independent quotas per API action (UploadLayerPart 500 TPS, InitiateLayerUpload / CompleteLayerUpload 100 TPS, PutImage 10 TPS). ocync tracks 9 separate AIMD windows so a 429 on uploads does not throttle manifest reads.

CLI example

# Pull from Chainguard (anonymous), push to your private ECR. Uses
# whatever AWS credentials are in scope; no docker login required.
ocync copy \
  cgr.dev/chainguard/static:latest \
  123456789012.dkr.ecr.us-east-1.amazonaws.com/static:latest

For sync-mode (multi-image, config-driven):

# ocync.yaml
registries:
  src:
    url: cgr.dev
  ecr:
    url: 123456789012.dkr.ecr.us-east-1.amazonaws.com

defaults:
  source: src
  targets: ecr

mappings:
  - from: chainguard/static
    to: static
ocync sync --config ocync.yaml

Kubernetes deployment

Two AWS-IAM paths are supported on EKS. Prefer EKS Pod Identity for new clusters; fall back to IRSA on clusters that have not adopted the Pod Identity Agent.

EKS Pod Identity

The successor to IRSA. Configured cluster-side via a PodIdentityAssociation resource that binds the chart’s ServiceAccount to an IAM role; no pod-spec annotation, no chart change. Requires the eks-pod-identity-agent addon on the cluster, and a trust policy on the IAM role allowing pods.eks.amazonaws.com.

# values.yaml
config:
  registries:
    src: { url: cgr.dev }
    ecr: { url: 123456789012.dkr.ecr.us-east-1.amazonaws.com }
  defaults:
    source: src
    targets: ecr
  mappings:
    - from: chainguard/static
      to: static

Create the association out-of-band (the chart’s default ServiceAccount is <release-name>-ocync):

aws eks create-pod-identity-association \
  --cluster-name my-cluster \
  --namespace ocync \
  --service-account my-release-ocync \
  --role-arn arn:aws:iam::123456789012:role/ocync-pod-identity

IAM Roles for Service Accounts (IRSA)

The original EKS workload-identity mechanism. The chart’s workloadIdentity.aws.roleArn adds the eks.amazonaws.com/role-arn annotation to the ServiceAccount; the AWS SDK uses the projected OIDC token to assume the role.

# values.yaml
config:
  registries:
    src: { url: cgr.dev }
    ecr: { url: 123456789012.dkr.ecr.us-east-1.amazonaws.com }
  defaults:
    source: src
    targets: ecr
  mappings:
    - from: chainguard/static
      to: static

workloadIdentity:
  provider: aws
  aws:
    roleArn: arn:aws:iam::123456789012:role/ocync-irsa

The IAM role’s trust policy must allow the cluster’s OIDC provider to federate the ServiceAccount.

FIPS endpoints

Set AWS_USE_FIPS_ENDPOINT=true to route ECR calls through *.dkr.ecr-fips.<region>.amazonaws.com:

env:
  - name: AWS_USE_FIPS_ENDPOINT
    value: "true"

For other secret-injection patterns (External Secrets Operator, CSI Secrets Store), see Kubernetes secrets.

Multi-account access

ocync uses one ambient AWS credential chain per process. Syncing across accounts (e.g., one source ECR plus several target ECRs in different accounts) means giving that one principal the right permissions for every account it touches. There are four patterns, in order of preference.

Cross-account ECR repository policies

Simplest. Attach a repository policy on each destination ECR repository that grants pull/push permissions to the principal ocync runs as. No assume-role hop, one set of credentials, the AWS SDK does no extra work.

{
  "Version": "2012-10-17",
  "Statement": [{
    "Sid": "AllowOcyncFromOriginAccount",
    "Effect": "Allow",
    "Principal": { "AWS": "arn:aws:iam::ORIGIN_ACCOUNT:role/ocync" },
    "Action": [
      "ecr:BatchGetImage",
      "ecr:BatchCheckLayerAvailability",
      "ecr:GetDownloadUrlForLayer",
      "ecr:InitiateLayerUpload",
      "ecr:UploadLayerPart",
      "ecr:CompleteLayerUpload",
      "ecr:PutImage"
    ]
  }]
}

Pair with ecr:GetAuthorizationToken on the ocync principal in the origin account. This works on every host (EKS, ECS, EC2, Lambda, local).

EKS Pod Identity with targetRoleArn

When repository policies aren’t an option (e.g., the destination accounts are owned by a different team and they prefer trust-policy-based access), EKS Pod Identity natively supports cross-account role chaining. Configure a PodIdentityAssociation with both roleArn (the local cluster role) and targetRoleArn (the role in the destination account):

aws eks create-pod-identity-association \
  --cluster-name my-cluster \
  --namespace ocync \
  --service-account my-release-ocync \
  --role-arn arn:aws:iam::ORIGIN_ACCOUNT:role/ocync-source \
  --target-role-arn arn:aws:iam::DESTINATION_ACCOUNT:role/ocync-target

The Pod Identity Agent assumes targetRoleArn for you; the credentials ocync sees are already the destination-account credentials. No ocync configuration needed.

Shared-config role chains (non-EKS)

On hosts that don’t use Pod Identity (ECS, EC2, on-prem, local dev), use the AWS shared-config role-chaining mechanism. Define a profile that names a source_profile and a role_arn, and run ocync with AWS_PROFILE=<chain-profile>:

# ~/.aws/config
[profile ocync-base]
region = us-east-1
# Resolves base credentials from env, IMDS, or another source

[profile ocync-target]
source_profile = ocync-base
role_arn = arn:aws:iam::DESTINATION_ACCOUNT:role/ocync-target
AWS_PROFILE=ocync-target ocync sync --config ocync.yaml

The AWS SDK handles the AssumeRole call and credential refresh transparently. The whole-process AWS_PROFILE mechanism applies one profile to every ECR registry; for per-registry overrides, see the next section.

Per-registry static credentials (third-party access)

Use this when one ECR registry needs credentials distinct from the ambient chain. The canonical case is a third-party ECR accessed with static IAM-user keys: Pod Identity / IRSA serves your own ECRs, and one specific registry uses keys the third party issued.

The aws_profile per-registry field scopes ECR credential resolution for that registry to a named AWS profile, leaving every other ECR registry on the ambient chain.

registries:
  my-source:
    url: 111111111111.dkr.ecr.us-east-1.amazonaws.com
    auth_type: ecr
    # no aws_profile -> ambient chain (Pod Identity, IRSA, env, IMDS)

  vendor-source:
    url: 222222222222.dkr.ecr.us-east-1.amazonaws.com
    auth_type: ecr        # required when aws_profile is set
    aws_profile: vendor   # reads [vendor] from the shared credentials file

Author the credentials file with the section the third party gave you:

[vendor]
aws_access_key_id = AKIA...
aws_secret_access_key = ...
# session_token = ...   # only if they issued STS temporary credentials

The AWS SDK reads the file from ~/.aws/credentials by default, or from the path in AWS_SHARED_CREDENTIALS_FILE. The file does not need a [default] section — the ambient chain skips the file entirely when no profile is named, so Pod Identity / IRSA still serves my-source.

For Kubernetes deployments, see the AWS shared-config files section of Kubernetes secrets for two production-grade injection patterns (External Secrets Operator and CSI Secrets Store).
